10 PRODIGIT
Power 300W 75W
Current 12A 15A
Voltage 500V 60V
6V @ 12A 0.3V @15A
Over Power Protection(OPP) 105% 105%
Over Current Protection(OCP) 105% 105%
Over Voltage Protection(OVP) 105% 105%
Over Temp Protection(OTP) YES YES
Range 0 ~ 1.2A 0 ~ 12A 0 ~ 1.5A 0 ~ 15A
Resolution 0.02mA 0.2mA 0.0254mA 0.25mA
Accuracy ± 0.05% of ( setting + Range)
Range 50 ~ 3000KΩ 0.5Ω ~ 50Ω 4Ω ~ 240 KΩ 0.02Ω ~ 4Ω
Resolution 0.000333mS 0.8333mΩ 0.04166mS 0.0666mΩ
Accuracy ± 0.2% of (Setting + Range)
Range 0 ~ 60V 0 ~ 500V 0 ~ 6V 0 ~ 60V
Resolution 0.001V 0.01V 0.0001V 0.001V
Accuracy ± 0.025% of (Setting + Range)
Range 0 ~ 30W 0 ~ 300W 0 ~ 7.5W 0 ~ 75W
Resolution 0.001W 0.01W 0.000125W 0.00125W
Accuracy ± 0.1% of (Setting + Range)
Algorithm P & O
Load mode CV
P&O interval 1000ms ~ 60000ms
Thigh & Tlow 0.050~9.999 / 99.99 / 999.9 / 9999mS
Resolution 0.001 / 0.01 / 0.1 / 1mS
Slew rate 0.8 ~ 50mA/uS 8.0 ~ 500mA/uS 1 ~ 62.5mA/uS 10 ~ 625mA/uS
Accuracy ± (5% of Setting) ±10uS
Range (5 Digital) 60V 600V 6V 60V
Resolution 0.001V 0.01V 0.0001V 0.001V
Accuracy ± 0.025% of (Reading + Range)
Range (5 Digital) 1.2A 30A 1.5A 15A
Resolution 0.0001A 0.001A 0.00001A 0.001A
Accuracy ± 0.1% of (Reading + Range)
Current Monitor FULL SCALE 10V
Accuracy 0.05% of (Setting + Range)
Current Programming Input FULL SCALE 10V
Programmable Short BUILT-IN
Load ON Voltage 0.4 ~ 100V 0.1 ~ 25V
Accuracy 1% of (Setting + Range)
Load OFF Voltage 0 ~ 100V 0 ~ 25V
Accuracy 0.025% of (Setting + Range)
Typical Short Resistance 0.5 Ω 0.02Ω
Table 1-1 3310F Series Specification
Note *1: The range is automatically or forcing to range II only in CC mode
Note *2: Power F.S. = Vrange F.S. x Irange F.S.
Note *3 : Operating temperature range is 0~40℃, All specifications apply for 25℃±5℃
