Chapter 2 Installation

This chapter details the installation and removal procedure of the 3310F series load module when used in

conjunction with the 3300F (quad module mainframe). The same procedure is used for the 3302F (single

module mainframe) and the 3305F (dual module mainframe).

Please note that the 3310F series load module does not need any user adjustment after it has been

plugged in to the mainframe.

Fig 2-1 Binding post and withdraw handle on the front panel of 3310F series Plug-in load module
