ASSEMBLY
A
ssembly requires two persons.
S
et the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, lubricant may be transferred to the top of the walking
belt or the shipping carton. This is a normal condition and does not affect treadmill performance. If there is lubri-
cant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex keys and your own phillips screwdriver ,wire cut-
ters , and adjustable spanner .
For help identifying assembly hardware, see the drawings below. Note: If a part is not found in the part bags,
check to see if the part has been preattached.
1
” Tek Screw
(
47)–8
3
1/4” x 1” Bolt
(88)–8
5/16” x 1” Bolt
(113)–4
1/2” Screw (52)–1
3/4” Screw (33)–5
1/4” Star Washer
(87)–8
1” Tek Screw
(123)–4
2
r
ew (123)–2
1” Silver Screw (92)–2
1 1/2” Screw (93)–2
(106)–4
H
(69)–2
5/16” x 3 1/2” Bolt (121)–2
5/16” Washer (130)–2
6
1. With the help of a second person, carefully raise the
Uprights (96) to the position as shown.
Insert one of the Extension Legs (86) into the treadmill as
shown. Make sure that the Extension Leg is turned so
the Base Pad (125) is underneath it. If necessary, tip the
Uprights (96) forward as you insert the Extension Leg.
Insert the other Extension Leg (not shown) in the same
way.
1
96
86
125
To Next Page
