ProMinent Beta BT4b - 8.1.3 Extern Contact

8.1.3 Extern Contact
In the Extern Contact operating mode,
either a series of strokes can
be triggered or an inbound series of contacts can be stepped down
via the pulse control switch by a single contact on the "External
control" terminal. To do so, the multifunctional switch has to be turned
to "Extern".
Explanation of the stepped-down values:
Settable values Incoming contacts Strokes performed
1:1 1 1
1:2 2 1
1:4 4 1
1:8 8 1
1:16 16 1
1:32 32 1
1:64 64 1
Explanation of stepped-up values:
Settable values Incoming contacts Strokes performed
1:1 1 1
2:1 1 2
4:1 1 4
8:1 1 8
16:1 1 16
32:1 1 32
64:1 1 64
8.2 Remote Operation
There is an option to control the pump remotely via a signal cable -
refer to your system documentation and to "Electrical Installation
".
"Extern" operating mode:
Operation
