ProMinent Beta BT4b - Climate; Protection Class and Safety Requirements

Specification Value Unit
Max. temperature long-term at max.
operating pressure
45 °C
Max. temperature for 15 min at max. 2
bar
60 °C
Minimum temperature -10 °C
Specification Value Unit
Max. temperature long-term at max.
operating pressure
45 °C
Max. temperature for 15 min at max. 2
bar
120 °C
Minimum temperature -10 °C
Specification Value Unit
Max. temperature long-term at max.
operating pressure
45 °C
Max. temperature for 15 min at max. 2
bar
120 °C
Minimum temperature -10 °C
Specification Value Unit
Max. temperature long-term at max.
operating pressure
45 °C
Max. temperature for 15 min at max. 2
bar
120 °C
Minimum temperature -10 °C
13.6.2 Climate
Specification Value Unit
Maximum air humidity *: 95 % rel.
humidity
* non-condensing
Exposure in a humid and alternating climate
:
FW 24 according to DIN 50016 (the standard was withdrawn in
2007).
13.7 Protection class and Safety Requirements
Protection against contact and humidity:
IP 65 in accordance with IEC 529, EN 60529, DIN VDE 0470 Part 1
NPT liquid end
PVT liquid end
TTT liquid end
SST liquid end
Degree of protection
Technical Data
44
