ProMinent diaLog DACb User Manual

Slot Index Name Module name Data type Byte
count
Total:
12 1 Additive
basic load
INT16 2
12 2 Control vari‐
able limit
UINT16 2
12 3 Delay after
stop
UINT16 2
12 4 Delay after
restart
UINT16 2
12 5 Setpoint 2 FLOAT 4 only with neu‐
tral zone con‐
trol
Controller
parameter
channel 3
‘controller
parameter ch3’
13 1 Additive
basic load
INT16 2
13 2 Control vari‐
able limit
UINT16 2
13 3 Delay after
stop
UINT16 2
13 4 Delay after
restart
UINT16 2
13 5 Setpoint 2 FLOAT 4 only with neu‐
tral zone con‐
trol
1.7 Bit field definitions
1.7.1 Status of the channel
Bit Description
15 1 = channel uses bus control parameters; 0 = channel uses internal parameters
14
13 1 = error exists; 0 = no error
12 1 = warning exists; 0 = no warning
11 1 = SD card full; 0 = SD card not full
10 1 = SD card free < 20%; 0 = SD card free ≧ 20%
9 1 = SD card exists; 0 = no SD card
8 1 = local control rate 2 active; 0 = local control rate 1 active
7
6
5
4
Supplementary Instructions for PROFINET
®
14
