1.7.5 Settings of the channel configuration
Bit Description
15 1 = Channel uses remote control parameters; 0 = Channel uses internal parameters;
[1 = Channel uses remote control parameters; 0 = Channel uses internal parameters]
14 1 = Channel uses internal set 2; 0 = Channel uses internal set 1;
[1 = Use internal parameter set 2; 0 = Use internal parameter set 1]
13
12
11
10
9
8 1 = Limit value 2 configuration on; 0 = limit value 2 configuration off
[1 = limit 2 configuration on; 0 = limit 2 configuration off]
7 1 = Limit value 1 configuration on; 0 = limit value 1 configuration off
[1 = limit 1 configuration on; 0 = limit1 configuration off]
6 0 = Control off;
[0 = Control off]
3 = P (1 way, decrease);
[3 = P (1 way, decrease)]
6 = PID (1 way, increase)
[6 = PID (1 way, increase) ]
9 = PID (2 way, dead zone)
[9 = PID (2 way, deadzone)]
1 = manual
[1 = manual]
4 = P (2 way, standard)
[ 4 = P (2 way, standard)]
7 = PID (1 way, decrease);
[7 = PID (1 way, decrease)]
2 = P (1 way, increase)
[2 = P (1 way, increase)]
5 = P (2 way, dead zone)
[5 = P (2 way, deadzone)]
8 = PID (2 way, standard)
[ 8 = PID (2way, standard)]
5
4
3
2
1 1 = Limit value 2 configuration high; 0 = limit value 2 configuration low;
[1 = limit 2 configuration high; 0 = limit 2 configuration off]
0 1 = Limit value 1 configuration high; 0 = limit value 1 configuration low;
[1 = limit 1 configuration high; 0 = limit 1 configuration off ]
n Bit 14 is only valid if bit 15 = 0
n Bit 3, 4, 5, 6 are only valid if bit 15 = 1
n Bit 3, 4, 5, 6, 14, 15 only exists on channels 1 and 2
Supplementary Instructions for PROFINET
®
19
