1.7.2 Error of the channel
Bit Description
31 Error 99: There is a system error;
[A system error exists]
30
29
28
27
26
25
24
23
22
21
20 Error 88: The connection to the extension module is faulty;
[The connection to the expansion module is faulty ]
19 Error 34: Incorrect correction variable;
[Incorrect correction variable ]
18 Error 19: The liquid level in storage tank 3 is too low;
[The level in tank 3 is too low ]
17 Error 18: The liquid level in storage tank 2 is too low;
[The level in tank 2 is too low ]
16 Error 17: The liquid level in storage tank 1 is too low;
[The level in tank 1 is too low ]
15 Error 16: The mA input is overloaded;
[The mA input is overloaded]
14 Error 15: The mA input supply is overloaded;
[The mA input supply is overloaded]
13 Error 14: The status of the controller is pause / hold
[PAUSE / HOLD]
;
[The controller is in the state PAUSE / HOLD]
12 Error 13: The status of the controller is pause
[PAUSE]
;
[The controller is in the state PAUSE]
11 Error 12: There is a sample water fault e.g. no flow;
[Error sample water exists, e. g. no flow]
10 Error 11: After elapse of the delay period, a limit value error still exists;
[After elapsing of the delay time a limit error still exists]
9 Error 10: The mA input current is less than 4 mA;
[The mA input current is less than 4 mA ]
8 Error 9: The mA input current is greater than 20 mA;
[The mA input current is greater than 20 mA ]
7 Error 8: The check time was infringed;
[The checkout time was infringed]
6 Error 7: Check the mechanical condition (glass breakage) of the sensor;
[Check the mechanical status of the sensor Glass break is possible]
5 Error 6: No sensor available;
[No sensor is available ]
4 Error 5: Calibration error exists;
[A calibration error exists]
3 Error 4: The temperature is too high;
[The temperature is too high]
2 Error 3: The temperature is too low;
[The temperature is too low ]
1 Error 2: The mV input voltage is too high;
[The mV input voltage is too high ]
0 Error 1: The mV input voltage is too low;
[The mV input voltage is too low ]
