1.6.3 Description of the DACa data objects
Tab. 2: Output data
Slot Index Name Module name Data type Byte
count
Total:
Output data
Channel 1 ‘Channel 1’
1 2 Measured
value
FLOAT 4
1 3 Controller
control vari‐
able
INT16 2
1 4 Temperature INT16 2 0.1 °C
1 5 Setpoint FLOAT 4
1 6 Channel
status
UINT16 2
Ä Chapter 1.7.1
‘Status of the
channel’
on page 14
1 7 Warnings UINT16 2
Ä Chapter 1.7.3
‘Warning of the
channel’
on page 17
Channel 2 ‘Channel 2’
2 2 Measured
value
FLOAT 4
2 3 Controller
control vari‐
able
INT16 2
2 4 Temperature INT16 2 0.1 °C
2 5 Setpoint FLOAT 4
2 6 Channel
status
UINT16 2
Ä Chapter 1.7.1
‘Status of the
channel’
on page 14
2 7 Warnings UINT16 2
Ä Chapter 1.7.3
‘Warning of the
channel’
on page 17
Channel 3 ‘Channel 3’
3 2 Measured
value
FLOAT 4
3 3 Controller
control vari‐
able
INT16 2
Supplementary Instructions for PROFINET
®
8
