ProMinent diaLog DACb User Manual

Slot Index Name Module name Data type Byte
count
Total:
3 4 Temperature INT16 2 0.1 °C
3 5 Setpoint FLOAT 4
3 6 Channel
status
UINT16 2
Ä Chapter 1.7.1
‘Status of the
channel’
on page 14
3 7 Warnings UINT16 2
Ä Chapter 1.7.3
‘Warning of the
channel’
on page 17
Channel 4
(differential
channel)
‘Channel 4’
4 1 Measured
value
FLOAT 4
4 2 Channel
status
UINT16 2
Ä Chapter 1.7.1
‘Status of the
channel’
on page 14
4 3 Warnings UINT16 2
Ä Chapter 1.7.3
‘Warning of the
channel’
on page 17
Digital out‐
puts
‘digital output’
5 1 Relay UINT16 2
Ä Chapter 1.7.4
‘Potential-free
relay’
on page 18
5 2 MosFET 1 UINT16 2 Frequency
5 3 MosFET 2 UINT16 2 Frequency
5 4 MosFET 3 UINT16 2 Frequency
5 5 MosFET 4 UINT16 2 Frequency
Error ‘errors’
Supplementary Instructions for PROFINET
®
9
