ProMinent diaLog DACb User Manual

Slot Index Name Module name Data type Byte
count
Total:
10 2 Error
channel 2
UINT32 4
0xFFFFFFFF
*
=> all pending
errors have
been con‐
firmed
Ä Chapter
1.7.2 ‘Error of
the channel’
on page 16
10 3 Error
channel 3
UINT32 4
0xFFFFFFFF
*
=> all pending
errors have
been con‐
firmed
Ä Chapter
1.7.2 ‘Error of
the channel’
on page 16
10 4 Error
channel 4
UINT16 2
0xFFFF *
=> all pending
errors have
been con‐
firmed
Ä Chapter
1.7.2 ‘Error of
the channel’
on page 16
* These errors can also be deleted/acknowledged individually.
Controller
parameter
channel 1
‘controller
parameter ch1’
11 1 Additive
basic load
INT16 2
11 2 Control vari‐
able limit
UINT16 2
11 3 Delay after
stop
UINT16 2
11 4 Delay after
restart
UINT16 2
11 5 Setpoint 2 FLOAT 4 only with neu‐
tral zone con‐
trol
Controller
parameter
channel 2
‘controller
parameter ch2’
Supplementary Instructions for PROFINET
®
13
