ProMinent diaLog DACb User Manual

Slot Index Name Module name Data type Byte
count
Total:
8 1 Configuration UINT16 2
Ä Chapter
1.7.5 ‘Settings
of the channel
configuration’
on page 19
(Parameter
via bus,
mode, limit
value direc‐
tion, control
time)
8 2 Limit value 1
value
FLOAT 4
8 3 Limit value 2
value
FLOAT 4
8 4 Setpoint 1 FLOAT 4
8 5 Xp FLOAT 4
Controller
channel 3
‘controller
channel 3’
9 1 Configuration UINT16 2
Ä Chapter
1.7.5 ‘Settings
of the channel
configuration’
on page 19
(Parameter
via bus,
mode, limit
value direc‐
tion, control
time)
9 2 Limit value 1
value
FLOAT 4
9 3 Limit value 2
value
FLOAT 4
9 4 Setpoint 1 FLOAT 4
9 5 Xp FLOAT 4
Error confir‐
mation
‘error
confirmation’
10 1 Error
channel 1
UINT32 4
0xFFFFFFFF
*
=> all pending
errors have
been con‐
firmed
Ä Chapter
1.7.2 ‘Error of
the channel’
on page 16
Supplementary Instructions for PROFINET
®
12
