36
Power relay output
for alarm triggering (XR3): Type of contact: Changeover contact, noise-suppressed
with varistors
Load capacity: 250 V AC, 3 A, 700 VA
Contact lifespan: >20 x 10
6
switching operations
IMPORTANT
The supply voltage applied at relays XR1-XR3 must be identical to the supply voltage
of XP.
Rated voltage (XP): 100/200 V AC, 50/60 Hz (D1C D only)
Maximum current intake: 150 mA at 100 V AC
75 mA at 200 V AC
Internal fuse protection with: 5 x 20 mm miniature fuse
160 mA, 250 V slow-blow
Rated voltage (XP): 115/230 V AC, 50/60 Hz
Maximum current intake: 140 mA at 115 V AC
70 mA at 230 V AC
Internal fuse protection with: 5 x 20 mm miniature fuse
160 mA, 250 V slow-blow
Rated voltage (XP): 24 V DC or 24 V AC, 50/60 Hz
(operation with safety extra-low voltage only!)
Internal fuse protection with: 5 x 20 mm miniature fuse
315 mA, 250 V slow-blow
Technical Data
