93-346-80 Issue 4 © Copyright Protec Fire Detection PLC 2011
5.0 Disabled Toilet Alarm
5.1 Connection Details
Disabled Toilet Alarms are used in-conjunction with the outstations; the toilet alarm does not have a
specific address location. Separate Text from the Outstation text can be allocated during
commission. Once activated via the pull cord the toilet alarm will be displayed on the main panel
and will either display the address of the outstation that the toilet alarm is connected to, or the
location text. A fast bleep will be the audio indication of the toilet alarm being activated, this can be
muted at the panel by pressing ‘Mute’.
ALARM DISABLED
TOILET
ALARM: DISABLED TOILET ALARM
LOCATION: SITE RELATED TEXT 1 ALARM
TIME: TIME / DATE
ENTER/FN: SCROLL
