Protec EVC40 - First City Toilet Alarm Connections

93-346-80 Issue 4 © Copyright Protec Fire Detection PLC 2011
23
5.2 Connection details for First City Toilet Alarm
Protec recommending the use of twisted pair cable (eg screened or unscreened CAT5) between the
disabled toilet alarm output and the outstation
Outstation Back
Box
ROLS
RRU Reset
PSU
RPC
Audio/Visual
Overdoor Light
+V
CH
Com
+V
CH
Com
CH
Com
CH
Com
Disabled +
Toilet -
Ceiling
Pull Cord
