6.0 Fire Input
The Fire Input signal allows the fire alarm system to control the operation of the EVC panel.
By connecting a normally closed contact from the fire alarm system to the fire input on the EVC panel all
outstations will be disabled until the fire alarm is activated. Only calls from the EVC panel to the
Outstations is in operation while the system is disabled. System Disabled will be displayed on the LCD
screen while the Fire Input is closed.
Once the fire input is open all outstations will be able to send and receive calls to and from the EVC
panel.
If the user requires continuous operation from the outstations then no connection to the fire input is
required.
Disabled Toilet Alarms will still function while the system is disabled.
PROTEC FIRE DETECTION PLC SYSTEM
DISABLED
22 MAY
09:29
