2.2 Log PDPS
The front panel of a control unit is the Phone Display Processors (PDPs), multiple PDPs are used when
Remote Control Units (RCUs) or Audio Loop Processors (ALPs) are used and more than 40 outstations
are required. Each PDP indicating the outstations programmed using PDP mapping software and
downloaded to the PDP.
Advanced menu option 2 - Log PDP - LCD displays R or L (stand alone panel only one address at
address 1). Enter to save.
This shows a system with 2 PDPs that have been logged before. Note that for PDPs the logging reports
only L or R.
1 PDPS FOUND, NO CHANGE
1 2 3 4 5 6 7 8 9 10
(01-10) R R - - - - - - - -
PRESS ENTER: SAVE, 1: RE-LOG AND 0: EXIT
1 PDPS FOUND, NO CHANGE
1 2 3 4 5 6 7 8 9 10
(01-10) R - - - - - - - - -
PRESS ENTER: SAVE, 1: RE-LOG AND 0: EXIT
