93-346-80 Issue 4 © Copyright Protec Fire Detection PLC 2011
With the loop break fixed and after saving and re-logging the display will become:
All devices are now R3 and information about missing devices is lost.
Interpreting Logging results
– No Device found at this address 1, 2 & 3 define connection status
L Newly Logged 1 - Outstation can be ‘seen’ from Line 1 only.
R Re-logged 2 - Outstation can be ‘seen’ from Line 2 only.
X Missing since last logged 3 - Outstation can be ‘seen’ from both sides.
Once the loop is logged there are seven options;
0 Exit logging menu
1 Log the loop again
2 Remembers the first number of logged devices and adds any new device to that total.
3 Display software versions of the outstations
4 Display group allocation in hexadecimal format
5 Display loop device type (0 = Disable Toilet, 1 = Simple Socket, 2 = Fire Telephone, 3 = Refuge
Point)
Enter Save the current changes.
17 DEVICES FOUND,
1 2 3 4 5 6 7 8 9 10
(01-10) - - - - - - - - - -
(11-20) - - - - - - - - - -
(21-30) R3 R3 R3 R3 R3 R3 R3 R3 R3 R3
(31-40) R3 R3 R3 R3 - R3 R3 R3 - -
PRESS ENTER: SAVE, 1: RE-LOG AND 0: EXIT
