Chapter 4 Award BIOS Setup
PS3100 SERIES USER
′
S MANUAL
Page: 4-17
ONCHIP IDE DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Phoenix – Award CMOS Setup Utility
OnChip IDE Device
Item Help
IDE HDD Block Mode
IDE DMA transfer access
OnChip Primary PCI IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Primary Master UDMA
IDE Primary Slave UDMA
OnChip Secondary PCI IDE
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE Secondary Master UDMA
IDE Secondary Slave UDMA
*** On-Chip Serial ATA Setting ***
SATA Mode
On-Chip Serial ATA
X PATA IDE Mode
SATA Port
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[IDE]
[Disabled]
Secondary
P0, P2 is
Primary
Menu Level ►
If your IDE hard drive
supports block mode
select Enabled for
automatic detection of
the optional number of
block read/writes per
sector the drive can
support.
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. IDE HDD BLOCK MODE:
Block mode is also called block transfer, multiple commands, or
multiple sector read/write. If your IDE hard drive supports block mode
(most new drives do), select Enabled for automatic detection of the
optimal number of block read/writes per sector the drive can support.
2. IDE DMA TRANSTER ACCESS:
To Enable/Disable the IDE DMA transfer access.
3. ONCHIP PRIMARY/SECONDARY PCI IDE:
The integrated peripheral controller contains an IDE interface with
support for two IDE channels. Select Enabled to activate each channel
