8. PROGRAMMING
The control panel is supplied with a SEQUENTIAL PROGRAMMING DEFAULT (obstacle detection excluded)
8.1 AUTOMATIC mode
8.1.1 AUTOMATIC mode with OBSTACLE DETECTION for double-leaf gates
ATTENTION!:
Before proceeding to programming, start a functional cycle test to proof the motors’ thrust.
The thrust has to be proper to the gate weight no matters if light or heavy gates.
If adjustments are needed, regulate POWER so that the gate doesn’t stop opposing a light contrast pressure.
• Start programming with cool operators.
• The AUTOMATIC MODE PROGRAMMING can only perform if mechanical ground endstops are fitted, in Opening
and Closing.
- Gate in CLOSING POSITION.
- SENS in half position.
- If during programming the gates stop before reaching the ground endstops, turn SENS (sensitivity) clockwise (to +).
- Press SET and keep pressed for 10 sec., DL1 starts blinking.
- When motors start working release SET.
- Motors run firstly a short OPENING for 4 sec., M1 first and M2 after (delayed leaf),
then CLOSE until the ground mechanical endstop in closing.
- At this stage the gate performs an OPENING RUN until fully open and a CLOSING RUN until fully close.
- When the procedure is finished, all time settings are saved.
The control panel is now ready for normal operation.
ATTENTION!:
Check the proper GATE OPERATION SENSITIVITY.
If adjustments are needed, turn SENS clockwise (to +) and regulate accordingly.
The sensitivity has to be proper in order to prevent uncorrect operation
OBSTACLE DETECTION OPERATION
- If an obstacle is detected in opening, the gate stops and reverses for 10 cm.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts.
If the area still remains unclear the gate stays open.
- If an obstacle is detected during slow down, the gate simply stops.
- If an obstacle is detected in closing, the gate stops and reverses till fully open.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts. If the area still remains
unclear the gate stays open.
- If an obstacle is detected during slow down, the gate simply stops.
- If power cut occurs, the first START cycle will perform without obstacle detection just to restore properly
the standard operation of the gate.
