Proteco myGate Q81A User Manual

1 2 3 4
ON ECE
1 2 3 4
ON ECE
SW1 SW2
1 2 3 4
ON ECE
ON
1 2 3 4
ON ECE
OFF
1 2 3 4
ON ECE
ON
1 2 3 4
ON ECE
OFF
1 2 3 4
ON ECE
ON
1 2 3 4
ON ECE
OFF
1 2 3 4
ON ECE
ON
1 2 3 4
ON ECE
OFF
Q81A_5_2021 13
6. OPERATION MODE
Choose the operation mode you wish selecting the switches SW1 – SW2.
The control panel is supplied with the following default settings:
How to
read switch
position:
ATTENTION:Turn the power off before setting the switches
SWITCH SW1
dip n° 1
dip n° 2
This function gives priority to the first open command. The control unit won’t accept additional
START commands during OPENING and AUTOMATIC CLOSING COUNT DOWN.
dip n° 3
dip n° 4
OFF = Double-leaf gate mode
ON = Single-leaf gate mode
OFF = Multi-occupation mode DEACTIVATED
ON = Multi-occupation mode ACTIVATED
OFF = Soft start mode DEACTIVATED
At opening motors work at the set thrust (POWER)
ON = Soft start mode ACTIVATED
At opening motors perform at maximum thrust for 1,5 sec.,
to continue after at the set thrust.
OFF = Motor and photocell TEST DEACTIVATED
ON = Motor and photocell TEST ACTIVATED
SOFT START
MOTOR TEST
PHOTOCELL TEST
ACTIVATED
WHITE switch DOWNWARD = Function OFF WHITE switch UPWARD = Function ON
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. +39 0173 210111 - Fax +39 0173 210199 info@proteco.net - www.proteco.net
