Q81A_5_2021 17
8.1.2 AUTOMATIC mode with OBSTACLE DETECTION for single-leaf gates
ATTENTION!:
The motor has to be wired to M1 input (orange terminal JP7, blocks 12 – 13 – 14)
- Switch SW1, dip no. 1 = ON.
- Gate in CLOSING position.
- SENS in half position.
- If during programming the gates stop before reaching the ground endstops, turn SENS (sensitivity) clockwise (to +).
- Press SET and keep pressed for 10 sec., DL1 starts blinking.
- When motor starts working release SET.
- Motor runs firstly a short OPENING for 4 sec., M1 first and M2 after (delayed leaf), then CLOSE until the ground
mechanical endstop in closing.
- At this stage the gate performs an OPENING RUN until fully open and a CLOSING RUN until fully close.
- When the procedure is finished, all time settings are saved.
The control panel is now ready for normal operation.
ATTENTION!:
Check the proper GATE OPERATION SENSITIVITY.
If adjustments are needed, turn SENS clockwise (to +) and regulate accordingly.
The sensitivity has to be proper in order to prevent uncorrect operation.
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. +39 0173 210111 - Fax +39 0173 210199 info@proteco.net - www.proteco.net
