Q81A_5_2021 19
Led ERROR
DL1 2 blinks
stop
2 blinks ....
3 blinks
stop
3 blinks ....
OFF
DL4 ON
DL5 OFF
DL7 OFF
DL8 OFF
DL6 ON
9. TROUBLE SHOOTING – ERROR MESSAGES
The control panel is designed to display errors through a LED lighting system.
Here below the trouble shooting table.
POSSIBLE CAUSE
• Photocell test
• Motor test
• Power supply disconnected
• Permanent START command
• STOP button disconnected
• Incorrect electric wiring
• Photocell in closing non-aligned
• Obstacle detected between the
photocells
• Incorrect electric wiring
• Disconnected photocell
• Disconnected photocell, active input
• Photocell in opening non-aligned
• Obstacle detected between the
photocells
• Incorrect electric wiring
• Disconnected photocell
• Permanent PEDESTRIAN command
SOLUTION
Check the wiring and operation of the photocell.
Check the wiring and operation of the motors.
Check the connection to the power supply
Check the operation of the ACCESSORIES wired
to the START (N.O. contact)
Check the wiring otherwise
(see section 3.5)
Check the wiring diagram
(see section 3.5)
Check the photocell alignment
Check and remove the obstacle
Check the wiring diagram
Check the power connection
Disable the photocell input (see section 3.6)
Check the photocell alignment
Check and remove the obstacle
Check the wiring diagram
Check the power connection
Check the operation of the ACCESSORIES wired
to the PEDESTRIAN START (N.O. contact)
+ blinker
Il nostro Servizio Assistenza è a tua disposizione
per qualsiasi chiarimento
sul prodotto, sull'installazione o sulla garanzia:
dal Lunedì al Venerdi, dalle 8.30 alle 12.00 e dalle 13.30 alle 17.00
346/4192300 info@mygateautomation.com
