Proton InteliSENS PD30 User Manual

Page 65 of 68
Proton Products InteliSENS PD30 Instruction Manual (Issue 1a)
DW
Bit
Comments
Unit
Range/Remark
Default value
DW123
Zero of analogue O/P3
1=1
0
DW124
DW125
Gain of analogue input
1=1
10000
DW126
Zero of analogue input
1=1
0
DW127
Parameter Group Number
1~50; 0 is not used
1
DW128
Parameter Group Control
1=Load parameters
from specified
group;2=Save current
parameters to
specified group
0
DW129
OUTPUT PARAMETERS
DW
Bit
Comments
Units
Range/Remark
DW0
0
Measurement Mode
0=Solid;1=Glass;2=Helix
1
2
3
Unit
0=Metric;1=Imperial
4
Shrinkage mode
0=Percentage;1=ABS
5
High Resoulation for Diameter
0=OFF;1=ON
6
Over average upper limit
0=OK;1=Over limit
7
Under average lower limit
0=OK;1=Over limit
8
Over X upper limit
0=OK;1=Over limit
9
Under X lower limit
0=OK;1=Over limit
10
Over Y upper limit
0=OK;1=Over limit
11
Under Y lower limit
0=OK;1=Over limit
12
Over Z upper limit
0=OK;1=Over limit
13
Under Z lower limit
0=OK;1=Over limit
14
Over ovality upper limit
0=OK;1=Over limit
15
Under ovality lower limit
0=OK;1=Over limit
DW1
0
Res
1
No reading
0=OK;1=No Reading
2
No object
0=OK;1=No Object
3
Window dirty
0=OK;1=Window Dirty
4
Line speed too low in helix mode
0=OK,1=too low
5
Line speed too high in helix mode
0=OK,1=too high
6
Gauge too hot
0=OK;1=Gauge Hot
7
8
External Alarm 1
0=OK,1=Alarm
9
External Alarm 2
0=OK,1=Alarm
