Proton InteliSENS PD30 User Manual

Page 66 of 68
Proton Products InteliSENS PD30 Instruction Manual (Issue 1a)
DW
Bit
Comments
Units
Range/Remark
DW2
Average diameter/Envelop
1=0.01um{mil}
0~20000000
DW3
DW4
X diameter
1=0.01um{mil}
0~20000000
DW5
DW6
Y diameter
1=0.01um{mil}
0~20000000
DW7
DW8
Z diameter
1=0.01um{mil}
0~20000000
DW9
DW10
Ovality
1=0.01um{mil}
0~20000000
DW11
DW12
Average error/Envelop Error
1=0.01um{mil}
-20000000~20000000
DW13
DW14
X error
1=0.01um{mil}
-20000000~20000000
DW15
DW16
Y error
1=0.01um{mil}
-20000000~20000000
DW17
DW18
Z error
1=0.01um{mil}
-20000000~20000000
DW19
DW20
Ovality error
1=0.01um{mil}
-20000000~20000000
DW21
DW22
Latest lump value
1=0.01um{mil}
-20000000~20000000
DW23
DW24
Latest lump positon
1=0.001m{1=0.001ft}
0~100000000
DW25
DW26
Latest neck value
1=0.01um{mil}
-20000000~20000000
DW27
DW28
Latest neck position
1=0.001m{1=0.001ft}
0~100000000
DW29
DW30
Lump count
1=1
0~65535
DW31
Neck count
1=1
0~65535
DW32
Running maximum diameter
1=0.01um{mil}
0~20000000
DW33
DW34
Running minimum diameter
1=0.01um{mil}
0~20000000
DW35
DW36
Running average diameter
1=0.01um{mil}
0~20000000
DW37
DW38
Cable position on X axis
1=1%
0~±100
DW39
Cable position on Y axis
1=1%
0~±100
