PS Engineering
PAC45 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-045-0000 Page 1-3 Rev. 7, May 2019
1.5 SPECIFICATIONS
TSO COMPLIANCE
Audio Selector/Intercom:
FAA TSO-C139A
APPLICABLE DOCUMENTS:
RTCA/DO-214A
RTCA/DO-160G
RTCA/DO-178C
ENVIRONMENTAL Qualifications:
A1D1BABSXXXXXXZBABZATTMA3J33XXA
Temperature Range:
Operating:
Short Term Operating:
Survival:
-20º C to +55ºC
-20°C to +70°C
-55º C to +85ºC Cold soak to –40˚C
Altitude:
Up to 55,000 feet in a non-pressurized area of the
cockpit.
DIMENSIONS:
Height: 1.9 in. (4.8 cm) Width: 5.75 in. (14.6 cm)
Depth behind panel (PAC45): 7.38 in. (18.75 cm) in-
cluding connectors
UNIT WEIGHT
PAC45 -001
HUB45
CTL45
2.0 lb. (0.90 kg)
1.0. (.45 kg)
1.0. (.45 kg)
POWER REQUIREMENTS :
Voltage:
18 to 33 VDC
Maximum Current:
Typical
Alert Power
Lighting
0.5 Amp (Externally protected by a 1 Amp circuit
breaker.)
PAC45 (Hub + CTL mated): 500mA
HUB45 only 350 mA
10 mA
CTL45 only: 150 mA
< 5mA
