72-900-06 Rev. F
Page 17 of 38
4.4 Main Menu
The Main menu is the starting point for all subsequent programming menus.
Relay HOA – This menu allows for the control of the relay output states, either
manual off, or auto.
Configure – This menu allows for setting the time and date, display contrast, water
meter, etc.
Settings – This menu allows for setting the conductivity, pH and ORP configurations
Timers– This menu allows for setting the timers for the different feed modes.
Communications– This menu allows for exporting data, exporting settings,
importing settings and upgrading the O/S.
4.5 Relay HOA
From the HOA Outputs menu manually set the relay control outputs. This is useful for
servicing chemical pumps or troubleshooting electrical problems. First select the relay
output to be controlled then select the relay state.
Forcing the output to Auto may cause the control output to energize without warning.
4.6 Configure
From the Configure menu select from many different system configuration options.
Date/Time – Set the current date, date format, time, and time format.
Digital Inputs – Set the drum level settings, and water meter type and volume.
4-20mA Out- Activate or deactivate 4-20mA output options.
4-20mA In- Activate or deactivate 4-20mA input options.
Gal/Lit- Set the units that the controller displays.
Meter Totals- Display and/or reset the water meter totals.
Language – Change the controller displayed language.
Display Settings – Set the display, brightness, home screen display text, home
screen scroll rate, home screen alarm message size, and the display dampener.
Password – Set the user password.
Software Version – Displays the current software version.
Factory Restore – Restore the parameters to factory default
4.6.1 Date/Time
From the Date/Time menu set the date and time as well as the date and time display
formats.
Set Date – Set the current date.
Set Time – Set the current time.
Date Format – Pick the day/month/year format.
Time Format – Pick the 12-hour or 24-hour time of day format.
