Pulseroller ConveyLinx-Ai2 Connecting

11
Using Generic Ethenret Module Method
Publication ERSC-1521 Rev 1.0 – February 2019
USING GENERIC ETHENRET MODULE METHOD
When using the Generic Ethernet Module construct in RSLogix 5000, you must supply configuration information
about the device you are trying to connect. The following sections show the step by step procedure to connect a
module for each set of Input and Output Assemblies described in publication ERSC-1506 ConveyLinx-Ai2 PLC
Developer’s Guide.
Each Assembly defined for ConveyLinx-Ai2 has a corresponding Assembly Instance value used when configuring your
Generic Ethernet Module in your RSLogix 5000 environment. The following chart is a reference showing all the
available Assemblies and their respective Instance Values used when connecting as a Generic Ethernet Device.
Assembly
Instance Values
ZPA Mode Assembly Inputs
105
ZPA Mode Assembly Outputs
106
ZPA Mode Assembly Inputs with Reset Protection
305
ZPA Mode Assembly Outputs with Reset Protection
306
Reduced Size ZPA Mode Assembly Inputs
119
Reduced Size ZPA Mode Assembly Outputs
120
Reduced Size ZPA Mode Assembly Inputs with Reset Protection
319
Reduced Size ZPA Mode Assembly Outputs with Reset Protection
320
PLC I/O Mode Assembly Inputs
107
PLC I/O Mode Assembly Outputs
108
PLC I/O Mode Assembly Inputs with Reset Protection
307
PLC I/O Mode Assembly Outputs with Reset Protection
308
Reduced Size PLC I/O Mode Assembly Inputs
117
Reduced Size PLC I/O Mode Assembly Outputs
118
Reduced Size PLC I/O Mode Assembly Inputs with Reset Protection
317
Reduced Size PLC I/O Mode Assembly Outputs with Reset Protection
318
ConveyLogix Assembly Inputs
121
ConveyLogix Assembly Outputs
122
