Pulseroller ConveyLinx-Ai2 Connecting

Publication ERSC-1521 Rev 1.0 – February 2019
16
Connecting to Rockwell PLCs
PARAMETERS FOR EACH ASSEMBLY
Please note that for all Assemblies and all versions of firmware the
Instance value for the “Configuration” parameter is always “1” and its size
is always “0”.
The following chart shows each available Assembly and its corresponding Input and Output Instance values and data
sizes:
Assembly
Type
Instance Value
Size Value
ZPA Mode Assembly
Input
105
21
Output
106
25
ZPA Mode Assembly with Reset Protection
Input
305
21
Output
306
25
Reduced Size ZPA Mode Assembly
Input
119
12
Output
120
15
Reduced Size ZPA Mode Assembly with Reset Protection
Input
319
12
Output
320
15
PLC I/O Mode Assembly
Input
107
23
Output
108
27
PLC I/O Mode Assembly with Reset Protection
Input
307
23
Output
308
27
Reduced Size PLC I/O Mode Assembly
Input
117
9
Output
118
9
Reduced Size PLC I/O Mode Assembly with Reset Protection
Input
317
9
Output
318
9
ConveyLogix Assembly
Input
121
16
Output
122
16
