Publication ERSC-1521 Rev 1.0 – February 2019
Connecting to Rockwell PLCs
INSTALLING THE AOIS INTO RSLOGIX 5000
After your EDS files have been installed; the next procedure is to install the Add On Instruction (AOI) files that you
downloaded.
Step 1
Right click on the Add On Instruction
folder in the explorer tree. From the
pop-up menu select Import Add On
Instruction.
Step 2
Navigate to the folder location where
you downloaded your AOIs, select
the file then click import. In this
example we are importing the AOI for
ZPA mode.
Note: The filenames shown are for example
only. The filenames you download from the
web site may be different and should be the
latest release.
