Publication ERSC-1521 Rev 1.0 – February 2019
Connecting to Rockwell PLCs
PREFACE
WHO SHOULD USE THIS MANUAL?
This manual is intended for users who need to utilize a Rockwell PLC equipped with Ethernet I/P capability to connect
to a ConveyLinx Ethernet network to access module status and control conveyor operation.
PREREQUISITES
You should have reviewed and understood publication ConveyLinx-Ai2 PLC Developer’s Guide (Insight Automation
publication ERSC-1500) before utilizing this manual’s instructions to physically connect your Rockwell PLC to a
ConveyLinx network.
This manual also assumes you have a solid working knowledge of both Rockwell PLC’s and the RSLogix 5000 / RSLogix
Designer development environments.
NOT INCLUDED IN THIS MANUAL
Because system applications vary; this manual assumes users and application engineers
have properly sized their PLC’s Ethernet port capacity to accommodate the quantity of
ConveyLinx module connections desired. Please refer to
specifications.
This manual is for ConveyLinx-Ai2 modules only. For information on how to connect
ConveyLinx ERSC modules please see publication Connecting ConveyLinx-Ai2 to Rockwell
PLCs (Insight Automation publication ERSC-1520)
