Pulseroller ConveyLinx-Ai2 Connecting

37
Using ERSC Add On Instructions (AOI) with RSLogix 5000
Publication ERSC-1521 Rev 1.0 – February 2019
Tag Name
Data
Type
Developers
Guide Register
Bit Description
O_ConveyMerge_Enable_PLC_Cntrl BOOL 4:0387 15
Enable PLC to Control ConveyMerge Priority &
Release
O_ConveyMerge_Priority
SINT
4:0387 (Lo Byte)
-
Numerical Value (0-3) to Set Merge Priority
O_ConveyStop_Command
INT
4:0020
-
Set Local ConveyStop Command
O_DA_Mode_Cmd_DnZn SINT 4:0375 (Lo Byte) -
Direction & Accumulation Mode Command Byte for
Downstream Zone
O_DA_Mode_Cmd_UpZn SINT 4:0365 (Lo Byte) -
Direction & Accumulation Mode Command Byte for
Upstream Zone
O_DA_Mode_Value_DnZn
SINT
4:0375 (Hi Byte)
-
Direction & Accumulation Mode Number of Zones
O_DA_Mode_Value_UpZn
SINT
4:0365 (Hi Byte)
-
Direction & Accumulation Mode Number of Zones
O_Enable_Module
BOOL
-
AOI Logic
Enable Output to Module
O_Jog_FWD_DnZn
BOOL
4:0184
10
Jog Forward for Local Downstream Zone
O_Jog_FWD_UpZn
BOOL
4:0104
10
Jog Forward for Local Upstream Zone
O_Jog_REV_DnZn
BOOL
4:0184
11
Jog Reverse for Local Downstream Zone
O_Jog_REV_UpZn
BOOL
4:0104
11
Jog Reverse for Local Upstream Zone
O_Maintenance_Stop_DnZn
BOOL
4:0184
13
Force Stop Local Downstream Zone
O_Maintenance_Stop_UpZn
BOOL
4:0104
13
Force Stop Local Upstream Zone
O_Release_DnZn BOOL 4:0185 AOI Logic
Release and Accumulate on Next at Downstream
Zone
O_Release_UpZn
BOOL
4:0105
AOI Logic
Release and Accumulate on Next at Upstream Zone
O_Sensor_Prt_P2_Left_Output_Enable
BOOL
4:0063
8
Enable Sensor Port Pin 2 Left to be an Output
O_Sensor_Prt_P2_Left_Output_Energize BOOL 4:0063 12
Energize Sensor Port Pin 2 Left, Output Enable must
be Energized
O_Sensor_Prt_P2_Right_Output_Enable
BOOL
4:0063
9
Enable Sensor Port Pin 2 Right to be an Output
O_Sensor_Prt_P2_Right_Output_Energize BOOL 4:0063 13
Energize Sensor Port Pin 2 Right, Output Enable must
be Energized
O_Speed_Motor_Left
INT
4:0040
-
Value in mm/sec for MDR or RPM x 10 for PGD
O_Speed_Motor_Right
INT
4:0064
-
Value in mm/sec for MDR or RPM x 10 for PGD
O_Sts_DnZn_Discharge_FWD SINT 4:0232 (Lo Byte) -
Set Downstream Discharge Zone Forward Status
Value
O_Sts_DnZn_Discharge_REV SINT 4:0232 (Hi Byte) -
Set Downstream Discharge Zone Reverse Status
Value
O_Sts_UpZn_Induct_FWD
SINT
4:0134 (Lo Byte)
-
Set Upstream Induct Zone Forward Status Value
O_Sts_UpZn_Induct_REV
SINT
4:0134 (Hi Byte)
-
Set Upstream Induct Zone Reverse Status Value
O_Tracking_DnZn DINT
4:0212 (MSW)
4:0213 (LSW)
-
Write 32 Bit Tracking Data for Local DnZn When
Accumulated.
O_Tracking_Induct_FWD DINT
4:0139 (MSW)
4:0140 (LSW)
- Set Forward Induct Tracking Value
O_Tracking_Induct_REV DINT
4:0237 (MSW)
4:0238 (LSW)
- Set Reverse Induct Tracking Value
O_Tracking_UpZn
DINT
4:0132 (MSW)
4:0133 (LSW)
-
Write 32 Bit Tracking Data for Local UpZn When
Accumulated.
O_WakeUp_DnZn
BOOL
4:0184
12
Wake Up Local Downstream Zone
O_WakeUp_UpZn
BOOL
4:0104
12
Wake Up Local Upstream Zone
