Pyle PLR34M User Manual

10
SPECIFICATION
GENERAL
Power Supply Requirements : DC 12 Volts, Negative Ground
Chassis Dimensions : 178 (W) x 97 (D) x 50 (H)
Tone Controls
- Bass (at 100 Hz) : ±10 dB
- Treble (at 10 kHz) : ±10 dB
Maximum Output Power
- Version V : 4x60 watts
Current Drain
Version V : 5Ampere (max.)
RADIO
For 2 Bands
FM
Frequency Coverage 87.5 to 108 MHz.
IF 10.7 MHz
Sensitivity (S/N=30dB) 4μV
Stereo Separation >25dB
AM
Frequency Coverage 520 to 1710 KHz
IF 450 kHz
Sensitivity (S/N=20dB) 36 dBuV

Pyle PLR34M Specifications

General

MP3 playback	Yes
CD-R playback	No
Audio formats supported	MP3, WMA
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	30
Display type	LCD
Product color	Black
Compatible memory cards	MMC, SD
