Pylontech PowerCube-M1-C User Manual

47
after correct
wiring
connection
and start up
procedure
Internal cable
issue
2. Open BMS case, check the connectivity and
reliability of the internal power supply cable
PMU issue
3. Open BMS case, use multimeter check PMU
12Vdc output and CMU LEDs. If neither is on,
please swap the PMU.
Other error
4. If problem remain, contact Pylontech service
engineer.
Section B During operation：
(1) Error Code checked from BMS (Modbus protocol Appendix IV or CAN ID 0*4250&0*4290):
*The ‘Failure Definition’ and ‘Failure Mode’ column is reference from Pylontech Modbus protocol
Appendix IV Error code 1 bits to present.
Failure
Type
Failure
Definition
Possible Reason
Solution
External
Input RV Err
（Bit4）
D+ D- reversely
connected
Check the external power cables of
the polarity and connection
External
DC OV ERR
input over
voltage error
（Bit3）
D+ D- voltage
extremely higher than
battery system
voltage
Check external inverter`s voltage
whether match with the battery system
or not.
External
Emergency
stop（Bit13）
Command by external
device via dry
contactor
Command by external device, not an
error actively report by Battery system.
Current
Leakage
Current
Leakage Error
（Bit21）
Current
Leakage >25mA
1.With insulation glove, disconnect the
battery system and contact Pylontech
service engineer.
Self-test
Self-test
module Initial
Error（Bit16）
Self-test failed
1. Restart
2.If problem remain, contact
Pylontech service engineer.
Self-test
Self-test
module
coulomb error
（Bit15）
Self-test failed
contact Pylontech service engineer.
Self-test
Self-test
module
detecting
amount error
（Bit14）
Self-test failed
contact Pylontech service engineer.
Self-test
Safety check
failure（Bit11）
Chip self-test failed
1.Restart
2.If problem remain, contact Pylontech
