Pylontech PowerCube-M1-C User Manual

62
Annex 4: System Turn OFF Progress List
Tick after
completion
No.
Item
Remark
☐
1
Turn off the switch between PCS and this battery string
(PowerCube-M1-C), or turn off the power switch of PCS,
to make sure no current through this battery string.
Refer to chapter
3.6.5.
☐
2
Turn off the “Power Output Switch” of the BMS.
Refer to chapter
3.6.5.
☐
3
Turn off the “Power Switch” of the BMS.
Refer to chapter
3.6.5.
☐
4
Turn off the “Power Switch” of the MBMS.
Refer to chapter
3.6.5.
☐
5
Turn off the UPS.
⚫ The UPS can turn on to check the equipment (PCS
or battery system etc.). Otherwise must turn off the
UPS to save its power.
Refer to chapter
3.6.5.
