Manual for Advance 10B/Advance 10F
System memory
l Provides three 168 pin 3.3V unbuffered 100/133MHz DIMM sockets.
l Supports both 100/133MHz SDRAM, VCM(Virtual Channel Memory) SDRAM.
l Minimum memory size is 8MB, maximum memory size is 1.5G MB.
On-board IDE
l Supports two PCI PIO and Bus Master IDE ports.
l Two fast IDE interfaces supporting four IDE devices including IDE hard disks and
CD - ROM drives.
l Supports up to mode 4 timing.
l Supports “Ultra DMA/33”Synchronous DMA mode transferring up to 33Mbytes/sec.
l Supports “Ultra DMA/66”Synchronous DMA mode transferring up to 66Mbytes/sec.
l Supports “Ultra DMA/100”Synchronous DMA mode transferring up to 100Mbytes/sec.
l Integrated 16x32bit buffer for IDE PCI Burst Transfers.
On-chip I/O
l One floppy port supporting up to two 3.5” or 5.25” floppy drives with
360K/720K/1.2M/1.44M/2.88M format.
l Two high speed 16550 fast compatible UARTs(COM1/COM2/COM3/COM4
selective) with 16-byte send/receive FIFOs.
l One enabled parallel port at the I/O address 378H/278H/3BCH with additional
bi-direction I/O capability and multi-mode as SPP/EPP/ECP (IEEE 1284 compliant).
l Circuit protection provided, preventing damage to the parallel port when a
connected printer is powered up or operates at a higher voltage.
l Supports LS-120 floppy disk drive and Zip drive.
l All I/O ports can be enabled/disabled in the BIOS setup.
On-chip Audio (Available for Advance 10B mainboard only)
l Build in VIA
®
82C686B
l Direct Sound AC’97 Audio and AC’97 2.1 codec compliant.
AGP SLOT
l Supports 4X mode & AGP 2.0 compliant.
Advanced features
l PCI 2.2 Specification compliant.
l Provides Trend ChipAwayVirus® On Guard and PC-Cillin software with killing virus
function.
l Provides four USB ports, onboard PS/2 mouse and PS/2 keyboard ports.
l Provides infrared interface.
l Support PC99 color- coding connector Specification
Introduction
10
