Manual for Advance 10B/Advance 10F
37
PNP/PCI Configuration Setup
Figure-7 PNP/PCI Configuration Setup Menu
The following indicates the options for each item and describes their meaning.
Item Option Description
l PNP OS Installed Yes Device resources assigned by PnP OS.
No Device resources assigned by BIOS.
l Reset Configuration Enabled The system BIOS will reset configuration data
Data once then automatically set this item as disabled.
Disabled Disables the configuration data function.
l Resources Manual Assigns the system resources ( IRQ and DMA)
Controlled By manually .
Auto Assigns system resources (IRQ and DMA) auto-
matically by BIOS.
l PCI/VGA Palette Enabled Enabled PCI/VGA Palette Snoop.
Snoop Disabled Disabled PCI/VGA Palette Snoop.
l Assign IRQ For Enabled Assigns the needed IRQ for the VGA card.
VGA Disabled Does not assign an IRQ for the VGA card, in
order to release the IRQ.
l Assign IRQ For Enabled Assigns an IRQ for USB. If an USB device is used
USB enables this item.
Disabled Does not assign an IRQ for USB.
l IRQ-3~IRQ-15 Legacy ISA The specified IRQ-x will be assigned to ISA only.
assigned to PCI/ISA PnP The specified IRQ-x will be assigned to ISA or PCI.
l DMA-0~DMA-7 Legacy ISA The specified DMA-x will be assigned to ISA only.
assigned to PCI/ISA PnP The specified DMA-x will be assigned to ISA or PCI.
Chapter 3
