Manual for Advance 10B/Advance 10F
Chapter 1
Introduction
Chapter 1
Introduction
Overview
The Advance 10B/Advance 10F green mainboard utilizes the Apollo Pro 133A chipset and
provides high performance and cost-effective PC/ATX platform to support Intel Celeron
TM
PPGA370
, Pentium
®
III FC-PGA processors, Cyrix-III processor .The VIA
®
VT82C686B
chipset provides new features with Ultra ATA/100. Equipped with three memory module
sockets to support PC100/PC133MHz SDRAM and VCM SDRAM. It also provides advanced
features such as Suspend to RAM, wake-up on LAN, wake-up on internal/external modem
. The green function is in compliance with the ACPI specification.
IMPORTANT: take note of difference between two . The Advance 10B mainboard is that of
the model with AC’97 codec, the Advance 10F mainboard is that of the model without AC’97
codec.
Key Features
Form factor
l ATX form factor of 305mm x210mm.
Microprocessor
l Supports all Intel
®
Pentium III(Coppermine) FC-PGA processors at 533/600EB/667/733/
800EB/866/933MHz/1000MHz and future processors with 133MHz bus speed.
l Supports all Intel
®
Pentium III(Coppermine) FC-PGA processors at 500/550/600/650/
700/750/800/850MHz and future processors with 100MHz bus speed.
l Supports all Intel
®
Celeron™ FC-PGA processors at 533/566/600/633/667/700/733MHz
and future processors with 66MHz bus speed.
l Supports all Intel
®
Celeron™ PPGA processors at 300/300A/333/366/400/433/466/
500/533MHz with 66MHz bus speed.
l Supports later processors Cyrix-III at 500/533/550/600/667MHz and future processors
l Supports 66/100/133MHz Front Side Bus.
l CPU core frequency = Bus speed x3, x3.5, x4, x4.5, x5, x5.5, x6, x6.5, x7, x7.5,
x8 or x7, X7.5, X8, X8.5, X9, X9.5, X10, X10.5, X11, X11.5, X12.(BIOS will detect the
CPU ratio)
l On-board 1.5V, 2.5V regulators .
Chipset
l Apollo Pro 133A chipset: VT82C694X, VT82C686B.
9
