Manual for Advance 10B/Advance 10F
34
l AGP Aperture Size 4~128 Sets the effective size of the Graphics Aperture
(MB) to be used in the particular PAC Configuration.
l AGP-4X Mode Enabled Supports 4X mode.
Disabled Does not support 4X mode.
l AGP Driving Control Auto The default setting is suggested.
manual
l AGP Driving Value EC Sets the AGP Driving Value when the 4X AGP
card runs incorrectly.
l AGP Fast Write Enabled Enable AGP Fast Write
Disabled Disable AGP Fast Write
l Onchip USB Enabled Enables the onchip USB controller.
Disabled Disables the onchip USB controller.
l USB Keyboard Enabled USB keyboard support is enabled.
Support Disabled USB keyboard support is disabled.
l Onchip Sound Auto Enable AC97 function.
Disabled Disable AC97 function.
Note: If you have conflicts with the onboard
audio, you may set to disable this function.
The item is available for Advance 10B mainboard
only.
l Onchip Modem Auto Enable MC97 function.
Disabled Disable MC97 function.
l CPU to PCI Write Enabled Enable CPU to PCI Write Buffer.
Buffer Disabled Disable CPU to PCI Write Buffer.
l PCI Dynamci Enabled Enable PCI Dynamci Bursting.
Bursting Disabled Disable PCI Dynamci Bursting.
l PCI Master 0 WS Enabled Enable PCI Master 0 WS Write.
Write Disabled Disable PCI Master0 WS Write.
l PCI Delay Enabled Enable PCI Delay Transaction.
Transaction Disabled Disable PCI Delay Transaction.
l PCI#2 Access #1 Enabled Enable PCI#2 Access #1 Retry.
Retry Disabled Disable PCI#2 Access #1 Retry.
l AGP Master 1 WS Enabled Enable AGP Master 1 WS Write.
Write Disabled Disabled AGP Master 1 WS Write.
l AGP Master 1 WS Enabled Enable AGP Master 1 WS Read.
Read Disabled Disabled AGP Master 1 WS Read.
l Memory Parity/ECC Enabled Enables the Error Checking&Correction if ECC
Check memory is used.
Disabled Disable the ECC function.
Award BIOS Description
