QDI ADVANCE 10F User Manual

Manual for Advance 10B/Advance 10F
39
l UART 2 Mode Standard Defines Serial Port 2 as standard serial port.
HPSIR Supports IRD mode.
ASK IR Supports SHARP ASK-IR protocol with maximum
baud rate up to 57600bps.
l Onboard Parallel 378/IRQ7, Defines onboard parallel port address and IRQ
Port 278/IRQ5, channel.
3BC/IRQ7
Disabled Onboard parallel port is disabled.
l Parallel Port Mode SPP Defines the parallel port mode as
EPP Standard Parallel Port (SPP), Enhanced
ECP, Parallel Port (EPP), or Extended
ECP+EPP Capabilities Port (ECP).
l ECP Mode Use 1, 3 Set DMA for ECP mode use.
DMA
l Parallel Port EPP EPP1.7 Set parallel port EPP type.
Type EPP1.9
The following items are available for Advance 10B mainboard only.
l Onboard Legacy Enabled the following item according as onboard audio to
Audio set
Disabled
l Sound Blaster Enabled Enabled Sound Blaster.
Disabled Disabled Sound Blaster.
l SB I/O Base 220H/240H Define SB I/O Base Address.
Address 260H/280H
l SB IRQ Select IRQ5~IRQ10 Select SB IRQ.
l SB DMA Select DMA0~DMA3 Select SB DMA .
l MPU-401 Enabled Enable MPU-401
Disabled Disable MPU-401
l MPU-401 I/O 310/313H~ Define MPU-401 I/O address.
Address 320-323H
l Game port Enabled Enable game port.
(200-207H) Disabled Disable game port.
Chapter 3
