QNAP TS-h 86 Series User Manual

Component TS-h686-D1602-8G TS-h886-D1622-16G
Others
Power supply unit 250W, 100-240V AC, 50/60 Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Sound level 18.6 dB(A) 20.4 dB(A)
Note
The sound level was tested at a bystander position, which is
within one meter of the NAS. The test NAS operated at low
speed with the maximum number of drives installed.
Fans • System: 1 x 80 mm, 12V DC fan
• CPU: 1 x 97 mm, 12V DC smart
fan
• System: 2 x 80 mm, 12V DC fan
• CPU: 1 x 97 mm, 12V DC smart
fan
Note
The preinstalled CPU fan is connected to fan connector 2. An
additional CPU fan can be installed using fan connector 1. For
details, see Right Panel.
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Security slot Kensington security slot
Note
For the list of compatible drive models, go to https://www.qnap.com/compatibility.
Package Contents
Item Quantity
TS-hX86 NAS 1
Power cord 1
Ethernet cables 2 x 1GbE (Cat 5e)
Drive tray keys 2
Screws for 2.5-inch drives TS-h686: 12
TS-h886: 18
Screws for 3.5-inch drives TS-h686: 12
TS-h886: 18
Heatsinks 2
Quick Installation Guide (QIG) 1
Components
TS-hx86 User Guide
Product Overview 6
