Front Panel
TS-h686
No. Component No. Component
1 M.2 SSD LEDs 5 USB 3.2 Gen 2 One Touch Copy Type-A port
2 Power button 6 Drive LEDs
3 Power LED 7 SSD LEDs
4 USB One Touch Copy button 8 -
TS-h886
No. Component No. Component
1 LCD panel 6 Power LED
TS-hx86 User Guide
Product Overview 7
