10. Verify that the module is recognized by the NAS.
a. Log in to QuTS hero as administrator.
b. Go to Control Panel > System > System Status > Hardware Information .
c. Check the value for Total memory.
Replacing Expansion Cards
The TS-h1283XU-RP supports selected expansion cards, some of which require QNAP low-profile PCIe
brackets. QNAP-branded expansion cards purchased from the company website are shipped with the
brackets necessary to fit all QNAP NAS models.
Note
A dual-port 10Gbase-T RJ45 network expansion card is pre-installed on PCIe 3.0 slot 3,
and a dual-port 10 GbE SFP+ network expansion card is pre-installed on PCIe 3.0 slot 4.
Warning
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Power off the NAS.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Remove the case cover.
For details, see Removing the Case Cover.
Warning
To avoid potential injury or damage to components, ensure that the drives and other internal
system components have cooled before touching them.
5. Remove the existing expansion card.
a. Remove the screw that secures the PCIe bracket to the chassis.
b. Hold the expansion card by the edges.
c. Carefully pull the card out of the slot.
TS-h1283XU-RP User Guide
Installation and Configuration 21
