LEDs
LEDs indicate system status and related information when the NAS is powered on. The following LED
information applies only when the drive is correctly installed and when the NAS is connected to the network.
For details on the location of the LEDs, see Front Panel.
LED Status Description
System Status Flashes green and red
alternately every 0.5
seconds
• The drive is being formatted.
• The NAS is being initialized.
• The operating system is being updated.
• RAID rebuilding is in progress.
• Online RAID Capacity Expansion is in progress.
• Online RAID Level Migration is in progress.
Red • The drive is invalid.
• The disk volume has reached its full capacity.
• The disk volume is about to reach its full capacity.
• The system fan is not functioning.
• An error occured when accessing (read/write) the data.
• A bad sector is detected on the hard drive.
• The NAS is in degraded read-only mode (two member
drives failed in RAID 5 or RAID 6 but the data can still
be read).
• A hardware self-test error occurred.
Flashes red every 0.5
seconds
The NAS is in degraded mode (one member drive failed in
RAID 1, RAID 5, or RAID 6).
Flashes green every 0.5
seconds
• The NAS is starting up.
• The NAS is not configured.
• A drive is not formatted.
Green The NAS is ready.
Off All drives are in standby mode.
Drive Green The drive is ready.
Flashes green The drive is being accessed.
Red A read/write error has occurred.
Flashes red The drive is being located in QuTS hero.
Expansion unit Orange An expansion unit is connected.
Off No expansion units are connected.
TS-h1283XU-RP User Guide
Basic Operations 35
