5. Remove the case cover.
a. Remove the screws that secure the case cover to the chassis.
b. Slide the cover back.
c. Lift the cover until it is completely detached from the chassis.
6. Remove the power supply unit.
Warning
To avoid potential injury or damage to components, ensure that the drives and other
internal system components have cooled before touching them.
a. Disconnect the power supply cables.
b. Remove the screws that secure the unit to the chassis.
TVS-x72XT User Guide
Installation and Conguration 32
