Adjust the envelope insert fingers position
If the Insert fingers position is not correct, adjust the fingers as follows:
Loosen the knurled knob C on top of each finger.1.
2. Adjust each finger A so that the tip enters about 5 mm (0.2 inch) into the envelope.
3. Re-tighten the knurled knob.
The fingers can be moved sideways to the desired position.
4. Place the outer fingers D about 5 to 10 mm (0.2 to 0.4 inch) from the edges of the
envelope.
Check the position of the insert fingers when changing to a different
type of envelope.
5. Tap the envelope button on the touch screen to fetch another envelope.
6. Make sure that the finger position is correct. If not, repeat the steps for adjusting the
fingers.
