When loading the maxiFeeder, make sure that the document/BREs
are positioned parallel in relation to the feeding plate assembly to
ensure correct feeding.
The feeding plate assembly will be shifted up automatically (when the system starts
processing) until documents/BREs are underneath the rubber paper pullers.
In case of long documents, use the feeding plate extension F to
support the documents.
Instead also an optional A4 or 11” support plate can be used to
support long documents. Ask your local distributor for more
information about these optional support plates.
To load documents:
DescriptionItem
Thumbwheel for adjusting side guidesA
5
English
69
| Page 69 | Jul-11-2022 07:45 | Loading the System
