Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Installation Manual • 2538-980 Rev. E • 5/19
E. Refractory
CAUTION! Risk of Cuts or Abrasions. Wear protective
gloves and safety glasses during installation.
NOTICE: Handle refractory panels with care. Refractory
may chip or crack if dropped or impacted.
KIT COMPONENTS (Refractory shown in Figure 1)
(1) Left Refractory
(1) Right Refractory
(1) Back Refractory
(1) Base Refractory
Leave this manual with party responsible for use
and operation.
Figure 2 Empty Firebox
Figure 1 Refractory Kit Components
INSTALLATION
1. Install base refractory. See Figure 3.
Figure 3 Base Refractory Installed
Service Parts:
If replacement panels are needed, the entire kit must be
ordered.
