Hearth&HomeTechnologieswelcomesyoutoourtradition
of excellence!  In choosing a Quadra-Fire appliance, you
haveourassuranceofcommitmenttoquality,durability,and
performance.
This commitment begins with our research of the market,
including ‘Voice of the Customer’ contacts, ensuring we
makeproducts that will satisfyyour needs. OurResearch
and Development facility then employs the world’s most
advancedtechnologytoachievetheoptimumoperationof
ourstoves,insertsandreplaces.Andyetweareold-fash-
ionedwhenitcomestocraftsmanship.Eachunitismeticu-
louslyfabricatedandsurfacesarehand-nishedforlasting
beautyandenjoyment.Ourpledgetoqualityiscompleted
aseachmodelundergoesaqualitycontrolinspection.
Wewishyou andyourfamilymanyyearsofenjoymentin
the warmth and comfort of your hearth appliance. Thank
youforchoosingQuadra-Fire.
Thisstovemustbeinstalledandcommissionedbya
trainedinstallerapprovedbySwitch.Aswellasthe
instructionsinthismanual,itisalsonecessarytotakeinto
considerationallapplicablelawsandstandardsaswell
asnational,regional,andlocalregulationsrelatingtothe
applianceinstallation.ItistheresponsibilityoftheInstaller
IMPORTANT
tocommissionthereinaccordancewithmanufacturer’s
instructionsandprovideadeclarationofconformityforthe
installationoftheapplianceifrequired.Pleasereadthis
User’sGuideandInstallationManualbeforeinstallingthe
stove.
WARNING
ThisapplianceanduesystemshallbeinstalledinaccordancewithAZ/NZS2918andtheappropriate
requirementsoftheNewZealandbuildingcode.
AppliancesinstalledinaccordancewiththisstandardshallcomplywiththerequirementsofAS/NZS4886where
requiredbytheregulatoryauthorityietheapplianceshallbeidentiablebyacomplianceplatewiththemarking
“testedtoAS/NZS4886”.
Anymodicationoftheappliancethathasnotbeenapprovedinwritingbythetestauthorityisconsideredtobein
breachoftheapprovalgrantedforcompliancewithAS/NZS.
