Quadra-Fire SANTA FE - A. Glass Specifications; B. kW & Efficiency Specifications; C. Specification Table

Page6
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
A. Glass Specications
Thisapplianceisequippedwith5mmceramicglass.
Replaceglassonlywith5mmceramicglass.Please
contactyourdealerforreplacementglass.
B. kW & Efciency Specications
kWinputwillvary,dependingonthebrandoffuelyouuse
inyourstove.Consultyourdealerforbestresults.
C. Specication Table
NOTE:Hearth&HomeTechnologies,manufacturerof
thisappliance,reservestherighttoalteritsproducts,their
specicationsand/orpricewithoutnotice.
WARNING! Risk of Fire!Hearth&HomeTechnologies
disclaimsanyresponsibilityfor,andthewarrantyand
agencylistingwillbevoidedbythebelowactions.
DO NOT:
 • Installoroperatedamagedappliance
 • Modifyappliance
 • InstallotherthanasinstructedbyHearth&Home
Technologies
 • Operatetheappliancewithoutfullyassemblingall
components
 • Overre
 • InstallanycomponentnotapprovedbyHearth&
HomeTechnologies
 • InstallpartsorcomponentsnotListedorapproved
 • Disablesafetyswitches
Improperinstallation,adjustment,alteration,serviceor
maintenancecancauseinjuryorpropertydamage.
Forassistanceoradditionalinformation,consultaqualied
installer,serviceagencyoryourdealer.
Classication Testing Standard Description
Class1IP-20
EfciencyAS/NZS5078:2007
ApplianceAS/NZS4886:2007
ResidentialWoodPelletHeater
Voltage220-240volts Current0.7-2.0Amps Frequency50Hz
MaxPowerRequirement
450Watts
Weight120kgwithfullhopper Hoppercapacity20kg
High Medium Low
Meanuegastemp
189°C
Meanuegastemp
166°C
Meanuegastemp
110°C
Fuelconsumption
1.9kg/hour
Fuelconsumption
1.4kg/hour
Fuelconsumption
0.7kg/hour
Heatingpoweroutput-7kW Heatingpoweroutput-5.2kW Heatingpoweroutput-2.7kW
Averageparticulateemissions
(dryweight)
0.4g/kg
Averageemissionrate
25mg/MJ
Averageefciency
71%
GrossCaloricvalueofpellets
(dryweight)
20.1MJ/kg
Fueltype
Woodpellets-6mmØ-complyingwithdraft
standardAS/NZS4014.6:2008
Specications
1
